class: center, middle, inverse, title-slide # An introduction to supervised machine learning ## Foundational Computational Biology I ### Kieran Campbell ### Lunenfeld Tanenbaum Research Institute & University of Toronto ### 2021-02-22 (updated: 2022-04-04) --- class: inverse # What we'll cover - What is supervised learning? - Continuous outputs: linear regression - Categorical outputs: logistic regression - A gallery of more sophisticated models - Controlling model complexity --- # What is supervised learning? -- Given some input data, we would like to train a model that _accurately_ predicts a corresponding output -- ## Examples -- 1. Given todays's weather (rainfall, hours of sunshine, average windspeed), will it rain tomorrow? - **Input**: today's weather, **output**: tomorrow's weather -- 2. Given a patient's laboratory test values (creatinine, glucose), does the patient have a particular disease? - **Input**: lab test values, **output**: diagnosis -- 3. Given a cancer biopsy gene expression measurement, what is the tissue of origin? - **Input**: gene expression for a given biopsy, **output**: cancer tissue of origin --- # What's special compared to other prediction types? -- Supervised machine learning explicitly involves 1. Past data where you _know_ the correct answer (input output pairs) 2. A model that we train on past data to get _good_ at predicting outputs given inputs -- Contrast this with: 1. **Rule based predictions**: e.g. if `blood glucose > 125mg/dL`, patient has diabetes 2. **Simulation based predictions**: e.g. use physics simulator to forward simulate tomorrow's weather, given today's -- ## When should we use supervised learning? If you have sufficient, <svg viewBox="0 0 576 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M528.1 171.5L382 150.2 316.7 17.8c-11.7-23.6-45.6-23.9-57.4 0L194 150.2 47.9 171.5c-26.2 3.8-36.7 36.1-17.7 54.6l105.7 103-25 145.5c-4.5 26.3 23.2 46 46.4 33.7L288 439.6l130.7 68.7c23.2 12.2 50.9-7.4 46.4-33.7l-25-145.5 105.7-103c19-18.5 8.5-50.8-17.7-54.6zM388.6 312.3l23.7 138.4L288 385.4l-124.3 65.3 23.7-138.4-100.6-98 139-20.2 62.2-126 62.2 126 139 20.2-100.6 98z"></path></svg> **unbiased** <svg viewBox="0 0 576 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M528.1 171.5L382 150.2 316.7 17.8c-11.7-23.6-45.6-23.9-57.4 0L194 150.2 47.9 171.5c-26.2 3.8-36.7 36.1-17.7 54.6l105.7 103-25 145.5c-4.5 26.3 23.2 46 46.4 33.7L288 439.6l130.7 68.7c23.2 12.2 50.9-7.4 46.4-33.7l-25-145.5 105.7-103c19-18.5 8.5-50.8-17.7-54.6zM388.6 312.3l23.7 138.4L288 385.4l-124.3 65.3 23.7-138.4-100.6-98 139-20.2 62.2-126 62.2 126 139 20.2-100.6 98z"></path></svg> data, it _may_ be better than other approaches --- class: top # What's different from supervised? Unsupervised learning (typically) has no outputs measured<sup>1</sup> -- Instead we "find structure" in the data -- ## Examples 1. **Netflix**: are there certain types of viewers who prefer particular genres? 2. **Clinical oncology**: are there subtypes of breast cancer that have similar prognosis / respond similarly to treatment? -- ### The line between supervised and unsupervised learning is not always clear cut! .footnote[ [1] Very common in biomedical applications ] <!-- --- --> <!-- class: center --> <!-- # Gene expression subtypes of pancreatic cancer --> <!-- ![PDAC subtypes](intro-ml_figs/pdac-subtypes.png) --> <!-- --- --> --- # The Big Picture Three ingredients of supervised ML 1. Some training data (input-output pairs) -- 2. A _model_ that maps **input data** to **output predictions** -- 3. A _loss function_ that measures the discrepancy between the **output prediction** and **output data** -- We aim to **iteratively improve the model to minimize the loss**. -- ## The Bigger Picture In probabilistic ML <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> maximize joint probability of the data given the model<sup>1</sup> .footnote[ [1] Or thereabouts ] --- class: center, middle, inverse # Starting a supervised learning project Always ask _is my output continuous or discrete?_ --- # Supervised learning .pull-left[ ## Continuous outputs * Typically known as _regression_ * Loss is often mean square error * Example models: * Linear regression * Polynomial / spline regression * Random forests * Deep neural networks ![](22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-2-1.png)<!-- --> ] -- .pull-right[ ## Discrete outputs * Typically known as _classification_ * Loss is often binary cross entropy * Example models: * Logistic regression regression * Naive Bayes * Support vector machines * Deep neural networks ![](22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-3-1.png)<!-- --> ] --- class: inverse, center, middle # Regression (continuous outputs) --- # Supervised ML Example problem: predict reduction in tumor volume given expression of a gene -- ## Notation `\(N\)` samples indexed by `\(n = 1, \ldots, N\)`, <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> `\(N\)` patients -- Input data `\(x_n \in \mathbb{R}\)` for each sample<sup>1</sup>, <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> expression of genes .footnote[ [1] In general high dimensional, but we can assume low dimensional here ] -- Output data `\(y_n \in \mathbb{R}\)` for each sample, _e.g. change in tumour volume_ -- A _model_ `\(f_\theta\)` parametrized by `\(\theta\)` that maps the inputs to predicted outputs `\(t_n\)`, i.e. `$$t_n = f_\theta(x_n)$$` -- - `\(t_n\)` is the predicted output for sample `\(n\)` - `\(y_n\)` is the actual output for sample `\(n\)` --- # Defining a loss We aim to adjust `\(\theta\)` to make `\(t_n\)` as _close_ to `\(y_n\)` averaged over `\(n\)` -- Define some _distance_ between `\(t_n\)` and `\(y_n\)` and minimize wrt `\(\theta\)` -- Common choice: mean squared error `$$\mathrm{MSE(\mathbf{t}, \mathbf{y})} = \frac{1}{N} \sum_{n=1}^N (y_n-t_n)^2$$` -- Remember this is still a function of `\(\theta\)`: `$$\mathrm{MSE(\mathbf{t}, \mathbf{y})} = \frac{1}{N} \sum_{n=1}^N (y_n-f_\theta(x_n))^2$$` --- # Linear regression So what is linear regression? -- `$$t_n = f_\theta(x_n) = wx_n + b$$` -- * Parameters `\(\theta = \{w,b\}\)` -- * `\(w\)` known as the _weight_, `\(b\)` the _bias_ -- * Loss now becomes `$$\mathrm{MSE(\mathbf{t}, \mathbf{y})} = \frac{1}{N} \sum_{n=1}^N (y_n-wx_n - b)^2$$` -- Iteratively adjust `\(w\)` and `\(b\)` to minimize `\(\mathrm{MSE(\mathbf{t}, \mathbf{y})}\)` --- # Minimizing losses So how do we minimize `\(\mathrm{MSE(\mathbf{t}, \mathbf{y})}\)`? Strategies: -- 1. Randomly guess<sup>1</sup> `\((w,b)\)` and choose the values that result in lowest `\(\mathrm{MSE(\mathbf{t}, \mathbf{y})}\)` .footnote[ [1] Not recommended ] -- 2. Differentiate `\(\mathrm{MSE(\mathbf{t}, \mathbf{y})}\)` w.r.t `\((w,b)\)`, set to 0, solve for `\((w,b)\)` -- 3. <svg viewBox="0 0 576 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M528.1 171.5L382 150.2 316.7 17.8c-11.7-23.6-45.6-23.9-57.4 0L194 150.2 47.9 171.5c-26.2 3.8-36.7 36.1-17.7 54.6l105.7 103-25 145.5c-4.5 26.3 23.2 46 46.4 33.7L288 439.6l130.7 68.7c23.2 12.2 50.9-7.4 46.4-33.7l-25-145.5 105.7-103c19-18.5 8.5-50.8-17.7-54.6zM388.6 312.3l23.7 138.4L288 385.4l-124.3 65.3 23.7-138.4-100.6-98 139-20.2 62.2-126 62.2 126 139 20.2-100.6 98z"></path></svg> Numerical methods <svg viewBox="0 0 576 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M528.1 171.5L382 150.2 316.7 17.8c-11.7-23.6-45.6-23.9-57.4 0L194 150.2 47.9 171.5c-26.2 3.8-36.7 36.1-17.7 54.6l105.7 103-25 145.5c-4.5 26.3 23.2 46 46.4 33.7L288 439.6l130.7 68.7c23.2 12.2 50.9-7.4 46.4-33.7l-25-145.5 105.7-103c19-18.5 8.5-50.8-17.7-54.6zM388.6 312.3l23.7 138.4L288 385.4l-124.3 65.3 23.7-138.4-100.6-98 139-20.2 62.2-126 62.2 126 139 20.2-100.6 98z"></path></svg> * Giant scientific field * _gradient descent_ increasingly popular <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> good in high dimensional problems where gradients of the loss w.r.t. the parameters are available --- class: inverse, center, middle # Logistic regression (discrete outputs) --- # Logistic regression * Previously: `\(y_n\)` was continuous <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> regression * Now: `\(y_n\)` binary i.e. `\(y_n = 0\)` or `\(1\)` <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> logistic regression -- Instead of modelling `\(y_n \approx t_n = wx_n + b\)` we're now interested in modelling $$p(y_n=1 | x_n) $$ -- Examples -- * `\(y_n=1\)` <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> patient has diabetes, `\(x_n\)` <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> blood glucose, `\(p(y_n=1 | x_n)\)` <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> "_what's the probability the patient has diabetes given the blood glucose measurement?_" -- * `\(y_n=1\)` <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> CRISPR guide RNA has off target effect, `\(x_n\)` <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> GC content -- As before, require `\((y_n, x_n)\)` _training points_ for `\(n=1,\ldots,N\)` --- # Loss function for logistic regression Let's define `\(\pi_n = p(y_n=1 | x_n)\)`. What is `\(p(y_n)\)` ? -- * If `\(y_n=1\)` then `\(p(y_n) = \pi_n\)` -- * If `\(y_n=0\)` then `\(p(y_n) = 1-\pi_n\)` -- We can write this as `$$p(y_n) = \pi_n^{y_n} (1-\pi_n)^{1-y_n}$$` -- For multiple observations `\(y_1, \ldots, y_N\)` we assume `$$p(y_1, \ldots, y_N) = \prod_{n=1}^N \pi_n^{y_n} (1-\pi_n)^{1-y_n}$$` -- Consider the log and maximize `$$\log p(y_1, \ldots, y_N) = \sum_{n=1}^N \left[ y_n \log(\pi_n) + (1-y_n) \log(1-\pi_n) \right]$$` --- # Logistic regression: modelling probabilities What's left? Need to specify how `\(\pi_n = p(y_n=1|x_n)\)` depends on `\(x_n\)` ! .pull-left[ Common choice: logistic function `$$\pi_n = \frac{1}{1 + \exp\left( -(wx_n + b) \right)}$$` ] .pull-right[ ![PDAC subtypes](intro-ml_figs/1280px-Logistic-curve.svg.png) ] -- Has the additional interpretation that the log-odds for a data point is linear in the covariates: `$$\log \frac{\pi_n}{1-\pi_n} = wx_n + b$$` ??? Many other possibilities for the function --- # Putting it all together Our loss: `$$l(w,b) = - \sum_{n=1}^N \left[ y_n \log(\pi_n) + (1-y_n) \log(1-\pi_n) \right]$$` where `$$\pi_n = \frac{1}{1 + \exp\left( -(wx_n + b) \right)}$$` -- Would like to minimize `\(l(w,b)\)` wrt `\(w,b\)` * Could use gradient descent as before since derivatives of `\(l\)` are computable * Better to use built-in implementations in R/Python/... --- # Logistic regression example .pull-left[ ![](22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-4-1.png)<!-- --> ] -- .pull-right[ ```r df <- data.frame(y = y, x = x) fit <- glm(y ~ x, data = df, family='binomial') df$predicted <- predict(fit, type='response') ggplot(df, aes(x = x, y = y)) + geom_point(alpha=.5) + geom_line(aes(y = predicted), colour='darkred', size=1.5) ``` ![](22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-5-1.png)<!-- --> ] --- class: inverse, center, middle # Moving past linear to more complex models --- # Moving past linear models So far we have modelled 1. [Linear regression] The predicted output `\(t_n(x_n)\)` 2. [Logistic regression] The conditional probabilities `\(p(y_n|x_n)\)` _linearly_ as a function of `\(x_n\)` via `\(wx_n + b\)` -- Almost certainly underestimates complexity of true relationship: * Higher order moments, e.g. `\(x^2, x^3\)` * Interactions between inputs, e.g. if `\(\mathbf{x_n}\)` is a vector, `\(x_{1,n} \times x_{2,n}\)` --- # Examples of more complex algorithms 1. Polynomial regression Model `\(y = m_0 + m_1 x + m_2 x^2 + m_3 x^3 + ...\)` -- 2. Decision trees / random forests Ask series of binary questions about input to arrive at output -- 3. Deep neural networks Model output as series of function compositions `\(y_n = f_K(f_{K-1}(...f_1(x_n)...))\)` where `$$f_k(x) = \sigma(wx+b)$$` `\(\sigma\)` often called _nonlinearity_, e.g. sigmoid, tanh, ReLU --- # Controlling model complexity .pull-left[ Consider `$$y_n = x_n \log(x_n) + \epsilon_n$$` `$$\epsilon_n \sim \text{N}(0,1)$$` > `\(\epsilon_n\)` is drawn from a **N**ormal distribution with mean 0 and standard deviation 1 ] -- .pull-right[ ```r set.seed(123456) x <- runif(100) y <- x * log(x) + rnorm(100, sd=0.1) qplot(x,y) ``` ![](22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-6-1.png)<!-- --> ] --- # Controlling model complexity .pull-left[ ## Linear fit ```r fit <- lm(y ~ x) df <- data.frame(x,y, t=predict(fit)) ggplot(df, aes(x=x)) + geom_point(aes(y=y)) + geom_line(aes(y=t), colour='red') ``` ![](22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-7-1.png)<!-- --> ] -- .pull-right[ ## High degree polynomial fit ```r fit <- lm(y ~ poly(x, 20)) df <- data.frame(x,y, t=predict(fit)) ggplot(df, aes(x=x)) + geom_point(aes(y=y)) + geom_line(aes(y=t), colour='red') ``` ![](22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-8-1.png)<!-- --> ] --- # How do we set the model complexity? -- Basic idea: tune model complexity by optimizing performance on held out dataset -- ![](intro-ml_figs/ML_dataset_training_validation_test_sets.png) .center[Credit: _Wikipedia_] --- # Practical example ## Create train and test datasets `\(y_n = x_n + 5 x_n^2 + \epsilon, \; \; x_n \sim \text{Unif}(0,1), \epsilon \sim \text{N}(0, 0.01)\)` ```r set.seed(123456) x_train <- runif(100); x_test <- runif(100) y_train <- x_train + 5 * x_train^2 + rnorm(100, sd=0.5) y_test <- x_train + 5 * x_train^2 + rnorm(100, sd=0.5) ``` -- ## Fit models on test sets ```r models <- lapply(1:20, function(i) { lm(y_train ~ poly(x_train, i)) }) ``` --- # Practical example ## Compute mean squared error on test set ```r mse <- sapply(models, function(fit) { test_predictions <- predict(fit, newdata=data.frame(x=x_test)) mean((y_test-test_predictions)^2) }) ``` ```r qplot(1:20, mse) + labs(x = "Degree of polynomial", y = "Mean squared error (test)") ``` <img src="22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-12-1.png" style="display: block; margin: auto;" /> --- # Overfitting and underfitting * If your model is too complex, it adapts to the noise in the training set <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> **overfitting** -- * If your model is too simple, it can't approximate the true function/decision boundary <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> **underfitting** -- .center[ <img src="intro-ml_figs/3x/model-complexity@3x.png" width=50%> ] -- * Closely related to bias-variance tradeoff --- # Controlling model complexity: penalized models Popular method for controlling model complexity is penalizing coefficient size -- Consider `\(P\)` input variables <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> `\(P\)` coefficients `$$y_n = \sum_{p=1}^P w_p x_{np} + \epsilon$$` -- Would like to keep entries of `\(\mathbf{w}\)` _small_ and/or _sparse_ -- Do this by minimizing `$$\text{MSE}(\mathbf{y}, \mathbf{t}) + \lambda \times \text{size}(\mathbf{w})$$` -- * How we specify `\(\text{size}(\mathbf{w})\)` gives different properties -- * `\(\lambda\)` controls the trade-off between predictive accuracy and model complexity -- * Typically set `\(\lambda\)` via optimizing accuracy on test set --- # Choice of penalties .pull-left[ ## L2 norm (_Ridge_) Set `\(\text{size}(\mathbf{w}) = \sqrt{\sum_{p=1}^P w_p^2}\)` Leads to non-sparse solutions with small coefficients ] -- .pull-right[ ## L1 norm (_Lasso_) Set `\(\text{size}(\mathbf{w}) = \sum_{p=1}^P |w_p|\)` Leads to sparse solutions Combination L2 + L1 norms _elasticnet_ ] -- ## Implementations R: [glmnet](https://web.stanford.edu/~hastie/glmnet/glmnet_alpha.html) Python: [sklearn](https://scikit-learn.org/stable/auto_examples/linear_model/plot_lasso_and_elasticnet.html) --- # Wrap up 1. Supervised learning requires existing input-output pair data -- 2. Output is continuous <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> regression <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg>mean square error -- 3. Output is binary <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> classification <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> binary cross entropy -- 4. We can minimize loss functions in multiple ways including gradient descent -- 5. Many complex models beyond linear including random forests and deep neural networks -- 6. Using too complex a model can lead to _overfitting_ -- 7. We can reduce model complexity by penalizing coefficient sizes -- 8. We can select model complexity by optimizing performance on a held-out test set --- # Resources * Bishop's _Pattern Recognition and Machine Learning_ is [free online](http://users.isr.ist.utl.pt/~wurmd/Livros/school/Bishop%20-%20Pattern%20Recognition%20And%20Machine%20Learning%20-%20Springer%20%202006.pdf) -- * [scikit-learn](https://scikit-learn.org/stable/) one stop python shop for everything machine learning * Many toy and real datasets readily available * `pipeline` functionality very useful -- [Kaggle](https://www.kaggle.com/) for competitions -- Not mentioned: **visualization** of data before anything is **key**! -- These slides: [camlab.ca/teaching](https://www.camlab.ca/teaching) --- --- background-image: url('intro-ml_figs/mountain.jpg') background-position: center background-size: contain class: inverse # Gradient descent You're at the top of a mountain, it's getting dark, and you need to get down -- * Your position `\((x,y)\)` is your parameter space `\((w,b)\)` to explore -- * Your height is `\(\mathrm{MSE(\mathbf{t}, \mathbf{y})}\)` you want to minimize -- ## Q: What's the strategy? -- Take successive little steps downhill until things flatten out -- ## Local optimality Note this doesn't guarantee you to get to the _bottom_, only to a much flatter region <svg viewBox="0 0 448 512" xmlns="http://www.w3.org/2000/svg" style="height:1em;fill:currentColor;position:relative;display:inline-block;top:.1em;"> [ comment ] <path d="M190.5 66.9l22.2-22.2c9.4-9.4 24.6-9.4 33.9 0L441 239c9.4 9.4 9.4 24.6 0 33.9L246.6 467.3c-9.4 9.4-24.6 9.4-33.9 0l-22.2-22.2c-9.5-9.5-9.3-25 .4-34.3L311.4 296H24c-13.3 0-24-10.7-24-24v-32c0-13.3 10.7-24 24-24h287.4L190.9 101.2c-9.8-9.3-10-24.8-.4-34.3z"></path></svg> Big problem depending on shape of your mountain / loss function --- # What is downhill? > successive little steps downhill -- .pull-left[ Consider `\(y=(x-1)^2\)`, `\(\frac{\mathrm{d}y}{\mathrm{d}x} = 2(x-1)\)` ] .pull-right[ <img src="22-introduction_to_supervised_learning_files/figure-html/unnamed-chunk-13-1.png" style="display: block; margin: auto;" /> ] -- Notice: * When `\(x > 1\)` we want to go to the _left_ and `\(\frac{\mathrm{d}y}{\mathrm{d}x} > 0\)` * When `\(x < 1\)` we want to go to the _right_ and `\(\frac{\mathrm{d}y}{\mathrm{d}x} < 0\)` The sign of the gradient always points uphill! --- # Gradient descent This suggests an iterative scheme: 1. Initialize some values for `\((w,b)\)` -- 2. For a given number of steps: * Update `\(w \leftarrow w - \epsilon \frac{\partial}{\partial w} \mathrm{MSE(\mathbf{t}, \mathbf{y}; w, b)}\)` * Update `\(b \leftarrow b - \epsilon \frac{\partial}{\partial b} \mathrm{MSE(\mathbf{t}, \mathbf{y}; w, b)}\)` -- 3. Monitor `\(MSE(\mathbf{t}, \mathbf{y}; w, b)\)` - if it "levels off" we can end with the optimal values `\((w,b)\)` -- ## Learning rate `\(\epsilon>0\)` is known as the _learning rate_ or _step size_. * Important parameter to tune: too large and you overshoot, too small and it's inefficient ---
